Standard Horizontal Feeder (GS-AAD2101/ GS-AAD2102)

Name: Standard Horizontal Feeder (GS-AAD2101/ GS-AAD2102)
Brand: Global Soul Limited
SKU: GS-AAD2101/ GS-AAD2102
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: GS

Model Number: GS-AAD2101/ GS-AAD2102

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Price: USD+negotiable+pcs

Packaging Details: 800*245*240mm

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:

Model:	GS-AAD2101	Overall Dimensions (length * Width * Height Unit: Mm):	570115140mm
Weight:	11KG	Working Voltage:	DC 24V
Gas Source Requirements:	No	Maximum Current:	3A
Feeding Speed:	1.5-2s/Pcs	Drive Mode:	Pure Electric
Operation Panel:	0.96-inch TFT Color Screen, 80*160 Pixels	Material Lifting Error:	±0.4mm
Applicable Tape Width:	66-87mm	The Pin Size Error After The Mold Is Formed:	±0.2mm

Model:	GS-AAD2101
Overall Dimensions (length * Width * Height Unit: Mm):	570115140mm
Weight:	11KG
Working Voltage:	DC 24V
Gas Source Requirements:	No
Maximum Current:	3A
Feeding Speed:	1.5-2s/Pcs
Drive Mode:	Pure Electric
Operation Panel:	0.96-inch TFT Color Screen, 80*160 Pixels
Material Lifting Error:	±0.4mm
Applicable Tape Width:	66-87mm
The Pin Size Error After The Mold Is Formed:	±0.2mm

Product Description

Standard Horizontal Feeder (GS-AAD2101/ GS-AAD2102)

The horizontal feeder is an electronic component supply device that keeps a certain interval and feeds out the horizontal tape-packed electronic components one by one at the prescribed time, shapes them and cuts the lead wires, and supplies them to the insertion machine.

Standard Horizontal Feeder (GS-AAD2101/ GS-AAD2102) 0

Standard Horizontal Feeder (GS-AAD2101/ GS-AAD2102) 1

1.1GS-AAD2102(110MM wide)

Standard Horizontal Feeder (GS-AAD2101/ GS-AAD2102) 2

Horizontal standard model (GS-AAD2101/ GS-AAD2102)
Applicable to the specifications of braided tape materials

Standard Horizontal Feeder (GS-AAD2101/ GS-AAD2102) 3

Standard Horizontal Feeder (GS-AAD2101/ GS-AAD2102) 4

If there are special material dimensions, you can contact our company for a solution and customize a dedicated feeder.
