SMT PCB Conveyor Unloader 220V with 6s Feed Time

Product Details

Place of Origin: China

Brand Name: GS

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Price: USD+negotiable+pcs

Packaging Details: 2000*1000*1300mm

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                smt pcb magazine loader, smt pcb handling machine


Description:	Used To Automatically Send Out Circuit Boards To The Production Line	No. Of Magazine:	Upper Conveyor: 1nos.Lower Conveyor:2nos
Time For Feed PCBs:	Approx. 6 Seconds Or Specified By Customer	Magazine Change Over Time:	Approx.35 Seconds Or Specified By Customer
Indexing Pitch:	10,20,30,40 Mm Pitch Or Specified By Customer	Power Supply And Electric Load:	220V(AC,SP)300VA Max
Air Pressure And Air Flow:	4~6bar, Up To 0.1	Thickness Of PBCs:	0.6mm Min

Description:	Used To Automatically Send Out Circuit Boards To The Production Line
No. Of Magazine:	Upper Conveyor: 1nos.Lower Conveyor:2nos
Time For Feed PCBs:	Approx. 6 Seconds Or Specified By Customer
Magazine Change Over Time:	Approx.35 Seconds Or Specified By Customer
Indexing Pitch:	10,20,30,40 Mm Pitch Or Specified By Customer
Power Supply And Electric Load:	220V(AC,SP)300VA Max
Air Pressure And Air Flow:	4~6bar, Up To 0.1
Thickness Of PBCs:	0.6mm Min

Product Description

SMT Series PCB Conveyor Machine Side Entry Unloader

Product Features

SMT production line circuit board upper board device
PLG control with color HMI operation system
Stepping motor push plate structure with adjustable pushing speed
Auxiliary positioning braking system for accurate positioning, fast lifting speed and high production efficiency
Multiple electrical distribution circuit protection for safe and reliable operation
Sound and light alarm system with abnormal information text prompts for easy operation and maintenance
Standard SMEMA signal communication
Optional AGV docking function

GSSMT, PCB side entry unloader, SMT side entry unloader, Side entry PCB handling, Side entry PCB unloader, SMT production line unloader, PCB assembly side unloader, PCB side access unloader, Fully automatic side unloader, Side entry SMT machine unloader, Side access conveyor system, PCB magazine side unloader
