Fuji NXT H01 Placement Head for Precise Placement Model Number AA15X12
Product Specifications
| Attribute |
Value |
| Brand Name |
FUJI |
| Product Name |
NXT H01 Head |
| Model Numbers |
AA15X18, AA15X12, AA15X17, AA15X25 |
| Condition |
Original New/Used Original |
| Lead Time |
1-7 Days |
Product Overview
The FUJI H01 HEAD is a highly adaptable and precise placement solution for FUJI's NXT series of modular placement machines. Designed for SMT (Surface Mount Technology) applications, it excels in handling diverse components while maintaining production efficiency and accuracy.
Key Features and Capabilities
- Single-nozzle head with exceptional accuracy and flexibility
- Handles components from 1608 (0603") to 74 x 74 mm in size
- Maximum component height capacity: 25.4 mm
- Placement accuracy of ±0.03 mm (Cpk ≥1.0)
- Throughput of up to 4,200 chips per hour (CPH)
- Compatible with standard SMT components and odd-form parts
Enhanced H01V Head Option
The H01V head features modified air routing that provides four times the holding capacity of the standard H01 head. This enhancement is ideal for components prone to warpage or requiring extra retention, ensuring secure pickup and placement while maintaining productivity.
Accessories and Options
- Nozzle Stations: Quick-change nozzle supply system
- Custom Nozzles: Specialized solutions for unique components
Applications
- Odd-form component placement
- Standard SMT component handling
- High-mix production environments
- Interposer placement (with H01V head)
Product Advantages
- Versatile component compatibility
- High-precision placement
- Reliable performance built to FUJI standards
- Enhanced retention options available
Frequently Asked Questions
What is the primary advantage of the FUJI H01 HEAD?
Its versatility in handling a wide range of component sizes and shapes, from standard SMT components to odd-form parts.
What kind of accuracy can be expected?
The FUJI H01 HEAD offers placement accuracy of ±0.03 mm (Cpk ≥1.0), ensuring precise and reliable placement.
What is the H01V head and how does it differ?
The H01V head is an enhanced version designed for parts requiring greater retention, featuring modified air routing that provides four times the holding capacity of the standard H01 head.
What machines are compatible?
The FUJI H01 HEAD is designed for FUJI's NXT series of modular placement machines, including the NXT M6 III and M6 IIIc models.
Are accessories available?
Yes, including nozzle stations for quick changes and custom nozzles for specialized components.
