Fuji NXT H08M Head with Backup Pin 2UGKHF000157

Name: Fuji NXT H08M Head with Backup Pin 2UGKHF000157
Brand: Global Soul Limited
SKU: 2UGKHF000157
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: Japan

Brand Name: FUJI

Model Number: 2UGKHF000157

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Price: USD+negotiable+pcs

Packaging Details: 600*350*360mm

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                H08M HEAD with Backup Pin, Fuji NXT H08M HEAD, 2UGKHF000157 Fuji NXT H08M HEAD


Brand Name:	FUJI	Product Name:	NXT H08M HEAD
Model Number 1:	2UGKHF000120	Model Number 2:	2UGKHF000114
Model Number 3:	2UGKHF000157	Condition:	Original New/Used Original

Brand Name:	FUJI
Product Name:	NXT H08M HEAD
Model Number 1:	2UGKHF000120
Model Number 2:	2UGKHF000114
Model Number 3:	2UGKHF000157
Condition:	Original New/Used Original

Product Description

Fuji NXT H08M HEAD with Backup Pin 2UGKHF000157

Product Specifications

Attribute	Value
Brand Name	FUJI
Product Name	NXT H08M HEAD
Model Number 1	2UGKHF000120
Model Number 2	2UGKHF000114
Model Number 3	2UGKHF000157
Condition	Original New/Used Original

Fuji NXT H08M Head with Backup Pin: Enhancing SMT Placement Accuracy and Efficiency

The Fuji NXT H08M Head with Backup Pin is a crucial component in surface mount technology (SMT) placement machines, known for its high accuracy and efficiency in component placement. This head is part of the Fuji NXT series, which is celebrated for its modular design and ability to adapt to various production needs.

Key Features and Benefits

High Accuracy: Placement accuracy of +/- 0.040 mm (3σ, Cpk≥1.00) ensures precise component placement on PCBs.
Component Range: Handles components from 0603 to 45 x 45 mm in size, with heights up to 13.0 mm.
Backup Pin Function: Automatically positions, checks, and fine-adjusts pins to reduce changeover time.
Speed and Throughput: 13,000 cph in standard mode and 14,000 cph in productivity priority mode.
Versatility: Compatible with Fuji NXT modules like M3 III and M6 III for flexible production configurations.

Integration and Compatibility

The Fuji NXT H08M Head supports intelligent feeders for various tape widths (4-104 mm) and stick feeders (4-32 mm part width). It is compatible with tray units for JEDEC standard trays and integrates seamlessly with Fuji NXT accessories and software.

Applications

Consumer Electronics: Smartphones, tablets, and other devices
Automotive Electronics: ECUs and control systems
Industrial Equipment: Control systems and machinery
Medical Devices: High-precision medical electronics

Frequently Asked Questions

What is the placement accuracy of the Fuji NXT H08M Head?

+/- 0.040 mm (3σ, Cpk≥1.00) under optimal conditions.

What is the component size range supported?

0603 to 45 x 45 mm in size, with heights up to 13.0 mm.

What is the throughput capacity?

13,000 cph (standard) and 14,000 cph (productivity priority mode).
