Home > products > SMT Feeders > Adjustable Tubular Feeder GS-SAT2203 Single Track for 400-600mm Material Pipes

Adjustable Tubular Feeder GS-SAT2203 Single Track for 400-600mm Material Pipes

Name: Adjustable Tubular Feeder GS-SAT2203 Single Track for 400-600mm Material Pipes
Brand: Global Soul Limited
SKU: GS-SAT2203
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: GS

Model Number: GS-SAT2203

Payment & Shipping Terms

Minimum Order Quantity: 1/PCS

Price: USD+negotiable+pcs

Packaging Details: 1650*100*560mm

Delivery Time: 1-3 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                Adjustable Tubular Feeder GS-SAT2203, GS-SAT2203 Tubular Feeder, GS-SAT2203


Model:	GS-SAT2203	Overall Dimensions (length * Width * Height):	156075450mm
Weight:	18KG	Working Voltage:	DC 24V
Gas Source Requirements:	0.5-0.7Mpa	Maximum Current:	2A
Feeding Speed:	＜2s/Pcs	Operation Panel:	0.96-inch TFT Color Screen, 80*160 Pixels
Pipe Replacement Time:	≤10S	Channel:	Single-channel/dual-channel( Default Single Channel)
Pin Bending Function:	Optional Separately(Default None)	Plastic Surgery Function:	Optional Separately(Default None)
Lifting Function:	Optional Separately(Default None)	Foot Cutting Function:	Optional Separately(Default None)
Adapt To The Length Of The Material Pipe:	400-600mm	Adapt To The Height Of The Material Pipe:	10mm-45mm
Adapt To The Width Of The Material Pipe:	10mm-40mm	Condition:	New

Model:	GS-SAT2203
Overall Dimensions (length * Width * Height):	156075450mm
Weight:	18KG
Working Voltage:	DC 24V
Gas Source Requirements:	0.5-0.7Mpa
Maximum Current:	2A
Feeding Speed:	＜2s/Pcs
Operation Panel:	0.96-inch TFT Color Screen, 80*160 Pixels
Pipe Replacement Time:	≤10S
Channel:	Single-channel/dual-channel( Default Single Channel)
Pin Bending Function:	Optional Separately(Default None)
Plastic Surgery Function:	Optional Separately(Default None)
Lifting Function:	Optional Separately(Default None)
Foot Cutting Function:	Optional Separately(Default None)
Adapt To The Length Of The Material Pipe:	400-600mm
Adapt To The Height Of The Material Pipe:	10mm-45mm
Adapt To The Width Of The Material Pipe:	10mm-40mm
Condition:	New

Product Description

Tubular Feeder (GS-SAT2203) [Single Track]

Adjustable Tubular Feeder GS-SAT2203 Single Track for 400-600mm Material Pipes 0

Detail display

Adjustable Tubular Feeder GS-SAT2203 Single Track for 400-600mm Material Pipes 1

Adjustable Tubular Feeder GS-SAT2203 Single Track for 400-600mm Material Pipes 2

Adjustable Tubular Feeder GS-SAT2203 Single Track for 400-600mm Material Pipes 3 If there are special material dimensions, you can contact our company for a solution and customize a dedicated feeder.
