GS-SAT2109 Tubular Feeder for Rail Vibration Feeding 10mm-28mm Pipe Width

Name: GS-SAT2109 Tubular Feeder for Rail Vibration Feeding 10mm-28mm Pipe Width
Brand: Global Soul Limited
SKU: GS-SAT2112
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: GS

Model Number: GS-SAT2112

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1/PCS

Price: USD+negotiable+pcs

Packaging Details: 1600*90*1250mm

Delivery Time: 1-3 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                10mm Tubular Feeder, Rail Vibration Tubular Feeder, GS-SAT2112 Tubular Feeder


Model:	GS-SAT2109	Overall Dimensions (length * Width * Height):	1500901140mm
Weight:	40KG	Working Voltage:	AC 220V
Gas Source Requirements:	0.5-0.7Mpa	Maximum Current:	3A
Feeding Speed:	2s/Pcs	Operation Panel:	1.54-inch OLED Display Screen
Pipe Replacement Time:	<6S	Channel:	Dual-channel
Pin Bending Function:	Optional Separately(Default None)	Plastic Surgery Function:	Optional Separately(Default None)
Lifting Function:	Optional Separately(Default None)	Foot Cutting Function:	Optional Separately(Default None)
Adapt To The Length Of The Material Pipe:	400-600mm	Adapt To The Height Of The Material Pipe:	10mm-45mm
Adapt To The Width Of The Material Pipe:	10mm-28mm	Condition:	New

Model:	GS-SAT2109
Overall Dimensions (length * Width * Height):	1500901140mm
Weight:	40KG
Working Voltage:	AC 220V
Gas Source Requirements:	0.5-0.7Mpa
Maximum Current:	3A
Feeding Speed:	2s/Pcs
Operation Panel:	1.54-inch OLED Display Screen
Pipe Replacement Time:	<6S
Channel:	Dual-channel
Pin Bending Function:	Optional Separately(Default None)
Plastic Surgery Function:	Optional Separately(Default None)
Lifting Function:	Optional Separately(Default None)
Foot Cutting Function:	Optional Separately(Default None)
Adapt To The Length Of The Material Pipe:	400-600mm
Adapt To The Height Of The Material Pipe:	10mm-45mm
Adapt To The Width Of The Material Pipe:	10mm-28mm
Condition:	New

Product Description

Tubular Feeder GS-SAT2112 for Rail Vibration Feeding

6S Pipe Replacement Adapted to 10mm-28mm Pipe Width

Product Specifications

Attribute	Value
Model	GS-SAT2109
Overall dimensions (L×W×H)	1500×90×1140mm
Weight	40KG
Working voltage	AC 220V
Gas source requirements	0.5-0.7Mpa
Maximum current	3A
Feeding speed	2s/Pcs
Operation panel	1.54-inch OLED display screen
Pipe replacement time	<6S
Channel	Dual-channel
Optional functions	Pin bending, Plastic surgery, Lifting, Foot cutting (available separately)
Material pipe compatibility	Length: 400-600mm \| Height: 10mm-45mm \| Width: 10mm-28mm
Condition	New

Product Description

The GS-SAT2109/2112 Tubular Feeder is a rail vibration feeding device designed for efficient supply of tube-mounted electronic components to insertion machines. Utilizing vibration and air blowing technology, it delivers components one by one at precise intervals.

Key Features

Rapid pipe replacement in under 6 seconds
Dual-channel operation for increased efficiency
1.54-inch OLED display for clear operation monitoring
Customizable with optional functions as needed
Wide compatibility with various material pipe dimensions

Custom Solutions Available

For special material dimensions, our engineering team can provide consultation and develop customized feeder solutions to meet your specific requirements.

Product Images
