GS-SHQ2304 Dual-Channel SMT Tube Feeder for IC Components

Name: GS-SHQ2304 Dual-Channel SMT Tube Feeder for IC Components
Brand: Global Soul Limited
SKU: GS-SHQ2304
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: GS

Model Number: GS-SHQ2304

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Price: USD+negotiable+pcs

Packaging Details: 1250*80*400

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                Surface Mount Ic Tube Mounting, GS-SHQ2304 Tube Mounting, Dual Track Ic Tube Mounting


Model:	GS-SHQ2304	Overall Dimensions (length * Width * Height):	118366303
Weight:	16.5KG	Working Voltage:	DC 24V
Gas Source Requirements:	0.4-0.7Mpa	Maximum Current:	2A
Feeding Speed:	0.6s/Pcs	Operation Panel:	0.96-inch TFT Color Screen, 80*160 Pixels
Pipe Replacement Time:	＜5S	Channel:	Dual-channel
Adapt To The Length Of The Material Pipe:	490-535mm	Adapt To The Height Of The Material Pipe:	3.5-5.5mm
Adapt To The Width Of The Material Pipe:	8/11/15mm	Material Length:	6.0~12.8mm
Material Width:	5.0~10.3mm	Material Height:	1.5~2.5mm

Model:	GS-SHQ2304
Overall Dimensions (length * Width * Height):	118366303
Weight:	16.5KG
Working Voltage:	DC 24V
Gas Source Requirements:	0.4-0.7Mpa
Maximum Current:	2A
Feeding Speed:	0.6s/Pcs
Operation Panel:	0.96-inch TFT Color Screen, 80*160 Pixels
Pipe Replacement Time:	＜5S
Channel:	Dual-channel
Adapt To The Length Of The Material Pipe:	490-535mm
Adapt To The Height Of The Material Pipe:	3.5-5.5mm
Adapt To The Width Of The Material Pipe:	8/11/15mm
Material Length:	6.0~12.8mm
Material Width:	5.0~10.3mm
Material Height:	1.5~2.5mm

Product Description

Surface Mount IC Tube Mounting (GS-SHQ2304) [Dual Track]

Product Specifications

Attribute	Value
Model	GS-SHQ2304
Overall dimensions (L×W×H)	1183×66×303 mm
Weight	16.5 kg
Working voltage	DC 24V
Gas source requirements	0.4-0.7 MPa
Maximum current	2A
Feeding speed	0.6s/Pcs
Operation panel	0.96-inch TFT color screen, 80×160 pixels
Pipe replacement time	＜5S
Channel	Dual-channel
Material pipe length compatibility	490-535mm
Material pipe height compatibility	3.5-5.5mm
Material pipe width compatibility	8/11/15mm
Material length	6.0~12.8mm
Material width	5.0~10.3mm
Material height	1.5~2.5mm

Product Description

The GS-SHQ2304 tubular feeder is a precision electronic component supply device designed for surface mount applications. This dual-track system delivers tube-mounted electronic components to the insertion machine through a combination of vibration and air blowing mechanisms, ensuring accurate and timely component placement.

For components with special dimensions, please contact our technical team for consultation. We can provide customized solutions and exclusive feeder configurations to meet your specific requirements.
