Surface Mount Ic Tube Mounting (GS-SHQ2304)[Dual Track]

Name: Surface Mount Ic Tube Mounting (GS-SHQ2304)[Dual Track]
Brand: Global Soul Limited
SKU: GS-SHQ2304
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: GS

Model Number: GS-SHQ2304

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Price: USD+negotiable+pcs

Packaging Details: 1250*80*400

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                Surface Mount Ic Tube Mounting, GS-SHQ2304 Tube Mounting, Dual Track Ic Tube Mounting


Model:	GS-SHQ2304	Overall Dimensions (length * Width * Height):	118366303
Weight:	16.5KG	Working Voltage:	DC 24V
Gas Source Requirements:	0.4-0.7Mpa	Maximum Current:	2A
Feeding Speed:	0.6s/Pcs	Operation Panel:	0.96-inch TFT Color Screen, 80*160 Pixels
Pipe Replacement Time:	＜5S	Channel:	Dual-channel
Adapt To The Length Of The Material Pipe:	490-535mm	Adapt To The Height Of The Material Pipe:	3.5-5.5mm
Adapt To The Width Of The Material Pipe:	8/11/15mm	Material Length:	6.0~12.8mm
Material Width:	5.0~10.3mm	Material Height:	1.5~2.5mm

Model:	GS-SHQ2304
Overall Dimensions (length * Width * Height):	118366303
Weight:	16.5KG
Working Voltage:	DC 24V
Gas Source Requirements:	0.4-0.7Mpa
Maximum Current:	2A
Feeding Speed:	0.6s/Pcs
Operation Panel:	0.96-inch TFT Color Screen, 80*160 Pixels
Pipe Replacement Time:	＜5S
Channel:	Dual-channel
Adapt To The Length Of The Material Pipe:	490-535mm
Adapt To The Height Of The Material Pipe:	3.5-5.5mm
Adapt To The Width Of The Material Pipe:	8/11/15mm
Material Length:	6.0~12.8mm
Material Width:	5.0~10.3mm
Material Height:	1.5~2.5mm

Product Description

Surface Mount Ic Tube Mounting (GS-SHQ2304)[Dual Track]

The tubular feeder is a tubular electronic component supply device that supplies tube-mounted electronic components to the insertion machine one by one at a specified time through vibration and air blowing.

Surface Mount Ic Tube Mounting (GS-SHQ2304)[Dual Track] 0

Surface Mount Ic Tube Mounting (GS-SHQ2304)[Dual Track] 1

If there are special material dimensions, you can contact our company for consultation and to provide solutions and customize exclusive feeders.
