GS-RDD2112 High Precision Radial Feeder with ±0.2mm Tolerance

Name: GS-RDD2112 High Precision Radial Feeder with ±0.2mm Tolerance
Brand: Global Soul Limited
SKU: GS-RDD2112
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: GS

Model Number: GS-RDD2112

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Price: USD+negotiable+pcs

Packaging Details: 900*90*300mm

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                GS-RDD2112 Radial Feeder, High Precision Radial Feeder, GS-RDD2112


Model:	GS-RDD2112	External Dimensions (length * Width * Height）:	79075205(180)mm（The Height From The Bottom To The Feeding Port: 180mm Height At The Highest Point (from The Bottom To The Handle) : 205mm）
Weight:	11KG	Working Voltage:	DC 24V
Gas Source Requirements:	No	Feeding Speed:	0.6-2s/Pcs
Drive Mode:	Pure Electric	Operation Panel:	0.96-inch TFT Color Screen 80*160 Pixels
Error In The Length Of The Material Cutting Feet:	±0.2mm	Applicable To The Hole Spacing Of The Tape:	12.7mm/15mm
Function Of Cutting Waste Tape:	Have	Bending Function:	Optional Separately（The Bending Function Can Be Customized According To The Material）
The Number Of Times The Cutter Is Used:	≥One Million	Condition:	New

Model:	GS-RDD2112
External Dimensions (length * Width * Height）:	79075205(180)mm（The Height From The Bottom To The Feeding Port: 180mm Height At The Highest Point (from The Bottom To The Handle) : 205mm）
Weight:	11KG
Working Voltage:	DC 24V
Gas Source Requirements:	No
Feeding Speed:	0.6-2s/Pcs
Drive Mode:	Pure Electric
Operation Panel:	0.96-inch TFT Color Screen 80*160 Pixels
Error In The Length Of The Material Cutting Feet:	±0.2mm
Applicable To The Hole Spacing Of The Tape:	12.7mm/15mm
Function Of Cutting Waste Tape:	Have
Bending Function:	Optional Separately（The Bending Function Can Be Customized According To The Material）
The Number Of Times The Cutter Is Used:	≥One Million
Condition:	New

Product Description

High Precision Radial Feeder GS-RDD2112 with ±0.2mm Material Cutting Feet Error Tolerance

Product Specifications

Attribute	Value
Model	GS-RDD2112
External dimensions (L×W×H)	790×75×205(180)mm (Height from bottom to feeding port: 180mm Height at highest point: 205mm)
Weight	11KG
Working voltage	DC 24V
Gas source requirements	None
Feeding speed	0.6-2s/Pcs
Drive mode	Pure electric
Operation panel	0.96-inch TFT color screen (80×160 pixels)
Error in length of material cutting feet	±0.2mm
Applicable tape hole spacing	12.7mm/15mm
Waste tape cutting function	Yes
Bending function	Optional (customizable based on material)
Cutter lifespan	≥1 million cycles
Condition	New

Product Description

Hook Type: Radial Feeder (GS-RDD2112)

The radial feeder is an electronic component supply device that maintains consistent intervals, delivers components from radial tape packaging one by one at specified times, cuts lead wires, and supplies them to the insertion machine.

Compatible with braided tape materials specifications:

For special material dimensions, please contact our company for consultation. We can provide solutions and customize exclusive feeders to meet your specific requirements.
