GS-RDD2105L Radial Feeder for SMT Components ≤14mm Width

Name: GS-RDD2105L Radial Feeder for SMT Components ≤14mm Width
Brand: Global Soul Limited
SKU: GS-RDD2105(L)
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: GS

Model Number: GS-RDD2105(L)

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Price: USD+negotiable+pcs

Packaging Details: 850*85*170mm

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                GS-RDD2105 L Radial Feeder, GS-RDD2105 L


Feeder Type:	GS-RDD2105（L）	Explain:	Feeder Reference Material Dimensions(mm)
Material Width:	≤14	Material Length:	≤14
Material Height:	≤30	Pin Spacing 1:	Standard Knife：≤10(Default Standard Knife)
Pin Spacing 2:	Wide Knife：8-13(Optional)	Pin Spacing 3:	Big Knife：8-23(Optional)
Pin Diameter:	The Largest1.0	Hole Spacing:	12.7or15(Default12.7)
Adjustable Range Of The Cutting Knife:	0-6(Based OnW+2)	The Distance From The Main Body To The Bending Point:	≥1.5
Braided Tape Height:	18	The Minimum Position Dimension Of The Foot Cutter:	2(The Minimum Residual Exposed Size After The Pins Are Cut)

Feeder Type:	GS-RDD2105（L）
Explain:	Feeder Reference Material Dimensions(mm)
Material Width:	≤14
Material Length:	≤14
Material Height:	≤30
Pin Spacing 1:	Standard Knife：≤10(Default Standard Knife)
Pin Spacing 2:	Wide Knife：8-13(Optional)
Pin Spacing 3:	Big Knife：8-23(Optional)
Pin Diameter:	The Largest1.0
Hole Spacing:	12.7or15(Default12.7)
Adjustable Range Of The Cutting Knife:	0-6(Based OnW+2)
The Distance From The Main Body To The Bending Point:	≥1.5
Braided Tape Height:	18
The Minimum Position Dimension Of The Foot Cutter:	2(The Minimum Residual Exposed Size After The Pins Are Cut)

Product Description

GS-RDD2105 L Radial Feeder

Material width ≤14mm | Material length ≤14mm

Product Specifications

Attribute	Value
Feeder type	GS-RDD2105（L）
Material width	≤14mm
Material length	≤14mm
Material height	≤30mm
Pin spacing 1 (Standard knife)	≤10mm (Default standard knife)
Pin spacing 2 (Wide knife)	8-13mm (Optional)
Pin spacing 3 (Big knife)	8-23mm (Optional)
Pin diameter	The largest 1.0mm
Hole spacing	12.7 or 15mm (Default 12.7mm)
Adjustable range of the cutting knife	0-6mm (Based on W+2)
The distance from the main body to the bending point	≥1.5mm
Braided tape height	18mm
The minimum position dimension of the foot cutter	2mm (The minimum residual exposed size after the pins are cut)

Vertical Feeder GS-RDD2105(L)

The Vertical feeder is an electronic component supply device that maintains precise intervals, delivering vertically packaged electronic components one by one at specified times. It cuts lead wires and supplies components to the insertion machine with high accuracy.

Bend Display

Specifications and Parameters

Braided Material Compatibility

For special material dimensions, please contact our company for consultation. We can provide customized solutions and exclusive feeder configurations to meet your specific requirements.
