Pure Electric Vertical Feeder GS-RDD2105 75068144 110 mm External Dimensions

Name: Pure Electric Vertical Feeder GS-RDD2105 750*68*144 110 mm External Dimensions
Brand: Global Soul Limited
SKU: GS-RDD2105
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: GS

Model Number: GS-RDD2105

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Price: USD+negotiable+pcs

Packaging Details: 900*85*145mm

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                GS-RDD2105 Electric Vertical Feeder, Pure Electric Vertical Feeder, GS-RDD2105


Model:	GS-RDD2105	External Dimensions (length * Width * Height）:	75068144(110)mm
Weight:	11KG	Working Voltage:	DC 24V
Gas Source Requirements:	No	Maximum Current:	3A
Feeding Speed:	0.6-2s/Pcs	Drive Mode:	Pure Electric
Operation Panel:	0.96-inch TFT Color Screen 80*160 Pixels	Error In The Length Of The Material Cutting Feet:	±0.2mm
Applicable To The Hole Spacing Of The Tape:	12.7mm/15mm[Parts Need To Be Replaced]	Function Of Cutting Waste Tape:	Have
Bending Function:	Optional Separately[The Bending Function Can Be Customized According To The Material]	The Number Of Times The Cutter Is Used:	≥1 Million

Model:	GS-RDD2105
External Dimensions (length * Width * Height）:	75068144(110)mm
Weight:	11KG
Working Voltage:	DC 24V
Gas Source Requirements:	No
Maximum Current:	3A
Feeding Speed:	0.6-2s/Pcs
Drive Mode:	Pure Electric
Operation Panel:	0.96-inch TFT Color Screen 80*160 Pixels
Error In The Length Of The Material Cutting Feet:	±0.2mm
Applicable To The Hole Spacing Of The Tape:	12.7mm/15mm[Parts Need To Be Replaced]
Function Of Cutting Waste Tape:	Have
Bending Function:	Optional Separately[The Bending Function Can Be Customized According To The Material]
The Number Of Times The Cutter Is Used:	≥1 Million

Product Description

Vertical Feeder (GS-RDD2105)

The vertical feeder is an electronic component supply device that keeps a certain interval and sends out the electronic components of the vertical tape packaging one by one at a specified time, cuts the lead wires, and supplies them to the insertion machine.

Pure Electric Vertical Feeder GS-RDD2105 750*68*144 110 mm External Dimensions 0

Pure Electric Vertical Feeder GS-RDD2105 750*68*144 110 mm External Dimensions 1

Detail display

Pure Electric Vertical Feeder GS-RDD2105 750*68*144 110 mm External Dimensions 4

Pure Electric Vertical Feeder GS-RDD2105 750*68*144 110 mm External Dimensions 5

If there are special material dimensions, you can contact our company for consultation and to provide solutions and customize exclusive feeders.
