GS-RAD2201 70mm Vertical Feeder with Optional Bending and Cutter

Name: GS-RAD2201 70mm Vertical Feeder with Optional Bending and Cutter
Brand: Global Soul Limited
SKU: GS-RAD2201
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: GS

Model Number: GS-RAD2201

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Price: USD+negotiable+pcs

Packaging Details: 900*95*175mm

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                70mm Vertical Feeder, GS-RAD2201 Vertical Feeder, GS-RAD2201


Model:	GS-RAD2201	External Dimensions (length * Width * Height）:	75068144(110)mm[The Height From The Bottom To The Feeding Port: 110cm Height At The Highest Point (from The Bottom To The Handle) : 144mm]
Weight:	8KG	Working Voltage:	DC 24V
Gas Source Requirements:	No	Maximum Current:	3A
Feeding Speed:	0.6-2s/Pcs	Drive Mode:	Pure Electric
Operation Panel:	0.96-inch TFT Color Screen 80*160 Pixels	Error In The Length Of The Material Cutting Feet:	±0.2mm
Applicable To The Hole Spacing Of The Tape:	12.7mm/15mm(Parts Need To Be Replaced)	Function Of Cutting Waste Tape:	Optional[ GS-RAD2201: With A Cutter GS-RAD2107: No Cutter]
Bending Function:	Optional Separately[The Bending Function Can Be Customized According To The Material]	The Number Of Times The Cutter Is Used:	≥1 Million

Model:	GS-RAD2201
External Dimensions (length * Width * Height）:	75068144(110)mm[The Height From The Bottom To The Feeding Port: 110cm Height At The Highest Point (from The Bottom To The Handle) : 144mm]
Weight:	8KG
Working Voltage:	DC 24V
Gas Source Requirements:	No
Maximum Current:	3A
Feeding Speed:	0.6-2s/Pcs
Drive Mode:	Pure Electric
Operation Panel:	0.96-inch TFT Color Screen 80*160 Pixels
Error In The Length Of The Material Cutting Feet:	±0.2mm
Applicable To The Hole Spacing Of The Tape:	12.7mm/15mm(Parts Need To Be Replaced)
Function Of Cutting Waste Tape:	Optional[ GS-RAD2201: With A Cutter GS-RAD2107: No Cutter]
Bending Function:	Optional Separately[The Bending Function Can Be Customized According To The Material]
The Number Of Times The Cutter Is Used:	≥1 Million

Product Description

GS-RAD2201 70mm Vertical Feeder with Optional Bending Function and Cutter

Product Specifications

Model	GS-RAD2201
External dimensions (L×W×H)	750×68×144(110)mm [Height from bottom to feeding port: 110mm Height at highest point (from bottom to handle): 144mm]
Weight	8KG
Working voltage	DC 24V
Gas source requirements	None required
Maximum current	3A
Feeding speed	0.6-2s/Pcs
Drive mode	Pure electric
Operation panel	0.96-inch TFT color screen (80×160 pixels)
Material cutting length error	±0.2mm
Applicable tape hole spacing	12.7mm/15mm (Parts need to be replaced)
Waste tape cutting function	Optional (GS-RAD2201: With cutter, GS-RAD2107: No cutter)
Bending function	Optional (Can be customized according to material requirements)
Cutter lifespan	≥1 million uses

Product Description

70mm Vertical Feeder (GS-RAD2201) - Ideal for large materials

The GS-RAD2201 vertical feeder is an advanced electronic component supply device designed for vertical tape packaging. It precisely maintains intervals and delivers components one by one at specified times, while optionally cutting lead wires for seamless integration with insertion machines.

For materials with special dimensions, please contact our technical team for consultation. We provide customized solutions and exclusive feeder configurations to meet your specific requirements.
