GS-RAZ2211 Electric Tape Feeder with Air Blowing 0.5MPa Gas Source

Name: GS-RAZ2211 Electric Tape Feeder with Air Blowing 0.5MPa Gas Source
Brand: Global Soul Limited
SKU: GS-RAZ2211
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: GS

Model Number: GS-RAZ2211

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Price: USD+negotiable+pcs

Packaging Details: 900*650*120

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                Air Blowing Tape Adjustment Feeder, Electric Drive Tape Adjustment Feeder, GS-RAZ2211 Tape Adjustment Feeder


Model:	GS-RAZ2211	Weight:	17KG
Working Voltage:	Ac 220V	Gas Source Requirements:	0.5MPa
Maximum Power:	400W(Direct Vibration: 330W)	Feeding Speed:	1.5s/Pcs
Drive Mode:	Electric[Blow Air To Assist In Throwing The Waste Tape]	Operation Panel:	0.96-inch TFT Color Screen 80*160 Pixels
Error In The Length Of The Material Cutting Feet:	±0.1mm	Applicable To The Hole Spacing Of The Tape:	12.7mm/15mm[ Parts Need To Be Replaced]
Applicable Material Body Height:	≤47mm	Applicable Material Pin Diameter:	≤0.8mm
Pin Span:	≤30mm	Function Of Cutting Waste Tape:	By Default, There Is[By Default, There Is None. Circular Materials Cannot Be Bent]
The Number Of Times The Cutter Is Used:	One Million	Condition:	New

Model:	GS-RAZ2211
Weight:	17KG
Working Voltage:	Ac 220V
Gas Source Requirements:	0.5MPa
Maximum Power:	400W(Direct Vibration: 330W)
Feeding Speed:	1.5s/Pcs
Drive Mode:	Electric[Blow Air To Assist In Throwing The Waste Tape]
Operation Panel:	0.96-inch TFT Color Screen 80*160 Pixels
Error In The Length Of The Material Cutting Feet:	±0.1mm
Applicable To The Hole Spacing Of The Tape:	12.7mm/15mm[ Parts Need To Be Replaced]
Applicable Material Body Height:	≤47mm
Applicable Material Pin Diameter:	≤0.8mm
Pin Span:	≤30mm
Function Of Cutting Waste Tape:	By Default, There Is[By Default, There Is None. Circular Materials Cannot Be Bent]
The Number Of Times The Cutter Is Used:	One Million
Condition:	New

Product Description

GS-RAZ2211 Tape Adjustment Feeder

Gas Source Requirements 0.5MPa Electric Drive with Air Blowing

Product Specifications

Attribute	Value
Model	GS-RAZ2211
Weight	17KG
Working voltage	AC 220V
Gas source requirements	0.5MPa
Maximum power	400W (Direct vibration: 330W)
Feeding speed	1.5s/Pcs
Drive mode	Electric (Blow air to assist in throwing the waste tape)
Operation panel	0.96-inch TFT color screen 80*160 pixels
Error in the length of the material cutting feet	±0.1mm
Applicable to the hole spacing of the tape	12.7mm/15mm (Parts need to be replaced)
Applicable material body height	≤47mm
Applicable material pin diameter	≤0.8mm
Pin span	≤30mm
Function of cutting waste tape	By default, there is (Circular materials cannot be bent)
The number of times the cutter is used	One million
Condition	New

Product Description

The GS-RAZ2211 vertical feeder is an electronic component supply device that maintains precise intervals and delivers vertically packaged electronic components one by one at specified times. It features:

Precision cutting of lead wires
Automated supply to insertion machines
Electric drive with air blowing assistance
High-resolution 0.96-inch TFT color screen operation panel
Exceptional cutting accuracy (±0.1mm)

For special material dimensions or custom requirements, please contact our technical team for consultation and customized feeder solutions.
