Large Electrolytic Capacitor Feeder GS-RAZ2304 Electronic Component

Name: Large Electrolytic Capacitor Feeder GS-RAZ2304 Electronic Component
Brand: Global Soul Limited
SKU: GS-RAZ2304
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: GS

Model Number: GS-RAZ2304

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Price: USD+negotiable+pcs

Packaging Details: 1350*150*1200mm

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                GS-RAZ2304 Electrolytic Capacitor Feeder, Large Electrolytic Capacitor Feeder, GS-RAZ2304 Electronic Component


Model:	GS-RAZ2304	External Dimensions (length * Width * Height）:	1152mm122.5mm900±40mm[For Details, Please Refer To The Size Diagram]
Weight:	20KG	Working Voltage:	Ac 220V
Maximum Power:	400W[Direct Vibration: 330W]	Feeding Speed:	1.5s/Pcs
Drive Mode:	Electric[ Blow Air To Assist In Throwing The Waste Tape]	Operation Panel:	0.96-inch TFT Color Screen 80*160 Pixels
Error In The Length Of The Material Cutting Feet:	±0.1mm	Applicable To The Hole Spacing Of The Tape:	12.7mm/15mm[ Parts Need To Be Replaced]
Applicable Material Body Height:	≤47mm	Applicable Material Pin Diameter:	≤0.8mm
Pin Span:	≤30mm	Function Of Cutting Waste Tape:	By Default, There Is
The Number Of Times The Cutter Is Used:	≥1 Million

Model:	GS-RAZ2304
External Dimensions (length * Width * Height）:	1152mm122.5mm900±40mm[For Details, Please Refer To The Size Diagram]
Weight:	20KG
Working Voltage:	Ac 220V
Maximum Power:	400W[Direct Vibration: 330W]
Feeding Speed:	1.5s/Pcs
Drive Mode:	Electric[ Blow Air To Assist In Throwing The Waste Tape]
Operation Panel:	0.96-inch TFT Color Screen 80*160 Pixels
Error In The Length Of The Material Cutting Feet:	±0.1mm
Applicable To The Hole Spacing Of The Tape:	12.7mm/15mm[ Parts Need To Be Replaced]
Applicable Material Body Height:	≤47mm
Applicable Material Pin Diameter:	≤0.8mm
Pin Span:	≤30mm
Function Of Cutting Waste Tape:	By Default, There Is
The Number Of Times The Cutter Is Used:	≥1 Million

Product Description

LARGE ELECTROLYTIC CAPACITOR FEEDER (GS-RAZ2304)

The vertical feeder is an electronic component supply device that keeps a certain interval and sends out the electronic components of the vertical tape packaging one by one at a specified time, cuts the lead wires, and supplies them to the insertion machine.

Large Electrolytic Capacitor Feeder GS-RAZ2304 Electronic Component 0

Large Electrolytic Capacitor Feeder GS-RAZ2304 Electronic Component 1

Large Electrolytic Capacitor Feeder GS-RAZ2304 Electronic Component 2

If there are special material dimensions, you can contact our company for consultation and to provide solutions and customize exclusive feeders.
