GS-RDD2105 Vertical Feeder 0.6-2s/Pcs Speed 3A Current

Name: GS-RDD2105 Vertical Feeder 0.6-2s/Pcs Speed 3A Current
Brand: Global Soul Limited
SKU: GS-RDD2105
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: GS

Model Number: GS-RDD2105

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Price: USD+negotiable+pcs

Packaging Details: 900*85*145mm

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                GS-RDD2105 Vertical Feeder, 3A Vertical Feeder, 0.6-2s/Pcs Vertical Feeder


Model:	GS-RDD2105	External Dimensions (length * Width * Height）:	75068144(110)mm
Weight:	11KG	Working Voltage:	DC 24V
Gas Source Requirements:	No	Maximum Current:	3A
Feeding Speed:	0.6-2s/Pcs	Drive Mode:	Pure Electric
Operation Panel:	0.96-inch TFT Color Screen 80*160 Pixels	Error In The Length Of The Material Cutting Feet:	±0.2mm
Applicable To The Hole Spacing Of The Tape:	12.7mm/15mm[Parts Need To Be Replaced]	Function Of Cutting Waste Tape:	Have
Bending Function:	Optional Separately[The Bending Function Can Be Customized According To The Material]	The Number Of Times The Cutter Is Used:	≥1 Million

Model:	GS-RDD2105
External Dimensions (length * Width * Height）:	75068144(110)mm
Weight:	11KG
Working Voltage:	DC 24V
Gas Source Requirements:	No
Maximum Current:	3A
Feeding Speed:	0.6-2s/Pcs
Drive Mode:	Pure Electric
Operation Panel:	0.96-inch TFT Color Screen 80*160 Pixels
Error In The Length Of The Material Cutting Feet:	±0.2mm
Applicable To The Hole Spacing Of The Tape:	12.7mm/15mm[Parts Need To Be Replaced]
Function Of Cutting Waste Tape:	Have
Bending Function:	Optional Separately[The Bending Function Can Be Customized According To The Material]
The Number Of Times The Cutter Is Used:	≥1 Million

Product Description

GS-RDD2105 Vertical Feeder with 0.6-2s/Pcs Feeding Speed and Maximum 3A Current

Product Specifications

Attribute	Value
Model	GS-RDD2105
External dimensions (L×W×H)	750×68×144(110)mm
Weight	11KG
Working voltage	DC 24V
Gas source requirements	No
Maximum current	3A
Feeding speed	0.6-2s/Pcs
Drive mode	Pure electric
Operation panel	0.96-inch TFT color screen (80×160 pixels)
Error in material cutting length	±0.2mm
Applicable tape hole spacing	12.7mm/15mm (Parts need to be replaced)
Cutting waste tape function	Yes
Bending function	Optional (Customizable according to material)
Cutter lifespan	≥1 million uses

Product Description

The GS-RDD2105 Vertical Feeder is an advanced electronic component supply device designed for precision manufacturing applications. It maintains consistent intervals while delivering vertically packaged electronic components at specified times, cutting lead wires, and supplying them to insertion machines with exceptional accuracy.

Detailed Features

For special material dimensions or custom requirements, please contact our technical team for consultation. We can provide tailored solutions and customize exclusive feeders to meet your specific production needs.
