SONY SI-F130 SMT Pick And Place Machine

Name: SONY SI-F130 SMT Pick And Place Machine
Brand: Global Soul Limited
SKU: SI-F130
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: Japan

Brand Name: SONY

Model Number: SI-F130

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Price: USD+negotiable+pcs

Packaging Details: 1500mm*1600mm*1750mm

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:

Equipment Model:	SI-F130	Soldering Head:	1 Head & 12 Nozzles
Feeder Quantity:	50	Vision System:	Optical Recognition System
Component Size:	Max: 6mm	Soldering Accuracy:	50um (CPK 1.0 Or Above)
PCB Size:	50mm50mm - 360mm1200mm	Component Thickness:	0402 (01005) - 12mm IC (mobile Camera) 6mm - 25mm IC (fixed Camera)
PCB Thickness:	0.5mm To 2.6mm	Operating Environment:	Ambient Temperature 15℃~30℃, Environmental Humidity 30%~70% (no Condensation Allowed)
Working Noise:	35-65 Decibels	Correction Method:	Machine Vision System, Multi-point MARK Vision Correction
Drive System:	AC Servo, AC Motor	Data Transmission:	USB Interface Input (EXCEL Document Format)
Operating System:	Chinese, English, Japanese Interface (WINDOWS System Control Platform)	Control Mode:	Fully Automatic
Soldering Speed:	0.139 Seconds (25900 CPH)	Equipment Dimensions (WDH):	1220mm X 1400mm X 1545mm
Equipment Weight:	1560KG

Equipment Model:	SI-F130
Soldering Head:	1 Head & 12 Nozzles
Feeder Quantity:	50
Vision System:	Optical Recognition System
Component Size:	Max: 6mm
Soldering Accuracy:	50um (CPK 1.0 Or Above)
PCB Size:	50mm50mm - 360mm1200mm
Component Thickness:	0402 (01005) - 12mm IC (mobile Camera) 6mm - 25mm IC (fixed Camera)
PCB Thickness:	0.5mm To 2.6mm
Operating Environment:	Ambient Temperature 15℃~30℃, Environmental Humidity 30%~70% (no Condensation Allowed)
Working Noise:	35-65 Decibels
Correction Method:	Machine Vision System, Multi-point MARK Vision Correction
Drive System:	AC Servo, AC Motor
Data Transmission:	USB Interface Input (EXCEL Document Format)
Operating System:	Chinese, English, Japanese Interface (WINDOWS System Control Platform)
Control Mode:	Fully Automatic
Soldering Speed:	0.139 Seconds (25900 CPH)
Equipment Dimensions (WDH):	1220mm X 1400mm X 1545mm
Equipment Weight:	1560KG

Product Description

Equipment Introduction: The SONY 130 series surface mounters come in three models: F130, F130AI, and F130WK, the classic models, which are of high quality. The speed can reach: 25,900 CPH (0.139S/chip) (SI-F130), using a CCD camera to identify components, with a unique image recognition system. SONY surface mounters, the globally unique planetary type mounting head, is fast and has high accuracy, improving the actual production efficiency. The globally unique rotating planetary type mounting head, with 12 suction nozzles, is fast and can achieve an actual output of up to 25,900 CPH/h. It is suitable for high-speed surface mounting of 1.2-meter LED light beads, the LED light bead surface mounting tool. F130 has a small footprint, low power consumption and air consumption, and low noise. The CCD camera identifies components, with a unique image recognition system, accurate positioning and high mounting accuracy.
