Fuji NXT M6S SMT Pick and Place Machine with ±0.025mm Accuracy

Product Details

Place of Origin: Japan

Brand Name: FUJI

Model Number: M6S

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1 pcs

Price: USD+negotiable+pcs

Packaging Details: 1800*1800*2100mm

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                High Precision Fuji SMT Pick And Place Machine, M6S Fuji SMT Pick And Place Machine, Pick And Place Machine For PCB Assembly


Model:	M6S	Series:	Fuji NXT Series
Category:	SMT Pick-and-place Machine	Accuracy:	±0.025 Mm (with Advanced Vision Recognition System)
Repeatability:	Highly Consistent With Advanced Servo Motors And Control Systems	Component Size Range:	From 01005 Chips (0.4 X 0.2 Mm) To Large, Odd-shaped Components Up To 74 Mm X 74 Mm
Component Types:	Can Handle A Wide Variety Of Components, Including Resistors, Capacitors, ICs, And Large Odd-form Components.	Configurable Modules:	The M6S Offers A Modular Architecture, Allowing For Flexibility In Machine Configuration According To Production Needs
Scalability:	Additional Modules Can Be Added To Enhance Production Capacity Or Diversify Functionality	Dual-Lane Operation:	Supports Dual-lane PCB Production, Allowing For Simultaneous Processing Of Different PCB Types
Feeder Capacity:	Supports Up To 130 Feeders Per Module Depending On Configuration	Feeder Type:	Intelligent Automatic Feeders For Quick Setup And Exchange
Feeder Options:	Compatible With Tape Feeders, Tray Feeders, Bulk Feeders, And Stick Feeders	Advanced Vision System:	Integrated High-resolution Cameras For Precise Component Recognition, Positioning, And Inspection
Maximum PCB Size:	508 Mm X 610 Mm (with Dual-lane Configuration)	Minimum PCB Size:	50 Mm X 50 Mm
PCB Thickness:	Supports A Wide Range Of PCB Thicknesses, From 0.3 Mm To 4.0 Mm	Machine Dimensions:	Approximately 1,300 Mm (L) X 1,300 Mm (W) X 1,600 Mm (H)

Model:	M6S
Series:	Fuji NXT Series
Category:	SMT Pick-and-place Machine
Accuracy:	±0.025 Mm (with Advanced Vision Recognition System)
Repeatability:	Highly Consistent With Advanced Servo Motors And Control Systems
Component Size Range:	From 01005 Chips (0.4 X 0.2 Mm) To Large, Odd-shaped Components Up To 74 Mm X 74 Mm
Component Types:	Can Handle A Wide Variety Of Components, Including Resistors, Capacitors, ICs, And Large Odd-form Components.
Configurable Modules:	The M6S Offers A Modular Architecture, Allowing For Flexibility In Machine Configuration According To Production Needs
Scalability:	Additional Modules Can Be Added To Enhance Production Capacity Or Diversify Functionality
Dual-Lane Operation:	Supports Dual-lane PCB Production, Allowing For Simultaneous Processing Of Different PCB Types
Feeder Capacity:	Supports Up To 130 Feeders Per Module Depending On Configuration
Feeder Type:	Intelligent Automatic Feeders For Quick Setup And Exchange
Feeder Options:	Compatible With Tape Feeders, Tray Feeders, Bulk Feeders, And Stick Feeders
Advanced Vision System:	Integrated High-resolution Cameras For Precise Component Recognition, Positioning, And Inspection
Maximum PCB Size:	508 Mm X 610 Mm (with Dual-lane Configuration)
Minimum PCB Size:	50 Mm X 50 Mm
PCB Thickness:	Supports A Wide Range Of PCB Thicknesses, From 0.3 Mm To 4.0 Mm
Machine Dimensions:	Approximately 1,300 Mm (L) X 1,300 Mm (W) X 1,600 Mm (H)

Product Description

High Precision M6S FUJI SMT Pick And Place Machine For PCB Assembly

The FUJI NXT M6S is part of FUJI's NXT series of high-performance SMT (Surface Mount Technology) machines. Designed for high-speed, precision component placement, this machine is ideal for modern electronics manufacturing.

Key Functions

High-Speed Component Placement: Capable of placing a wide variety of components at high speeds, from small chip components to larger, more complex parts.
Flexible Production Capabilities: Supports a wide range of PCB sizes and shapes, suitable for both small and large-scale production runs.
Modular Design: Customizable configuration with modules that can be easily added or removed to meet production demands.
Smart Nozzle Features: Intelligent nozzles automatically change depending on the component being placed, improving accuracy and reducing setup times.
Multi-Function Heads: Placement heads designed to handle multiple component types and sizes, increasing efficiency.
High Precision Vision System: Advanced vision systems ensure precise alignment and placement of components, maintaining quality control.

Key Features

Compact Size: Designed to take up minimal floor space, ideal for manufacturers with limited space.
High Component Variety: Supports components from 01005 size chips to larger ICs or connectors.
Auto-Calibration: Automatically calibrates for optimal performance, reducing manual setup time.
Reduced Downtime: Quick changeover features and modular design optimize operational efficiency.
User-Friendly Interface: Intuitive graphical user interface for easy programming and control.
Energy Efficiency: Energy-saving features make it more eco-friendly than older models.

This machine is ideal for manufacturers requiring flexibility, high precision, and fast turnaround in SMT production.
