Nitrogen / Air Wave Soldering Machine Lead Free for electronics

Name: Nitrogen / Air Wave Soldering Machine Lead Free for electronics
Brand: Global Soul Limited
SKU: SA-450
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: GS

Model Number: SA-450

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Price: USD+negotiable+pcs

Packaging Details: 4400*1680*1750mm

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                Nitrogen Wave Soldering Machine, Wave Soldering Machine Lead Free


Model:	SA-450	Basic Size/PCB:	Max450mm
Transfer Speed:	400 -1800mm/min	Preheater Power:	21.6KW
Tin Furnace Power:	18KW	Transmission Motor:	1ΦPAC220V 90W
Cooling Fan:	1ΦAC220V 370W	Tin Wave Motor:	2-3ΦPAC220V 370W
Cleaning Motor:	1ΦPAC220V 30W	Tin Furnace Capacity:	520kg

Model:	SA-450
Basic Size/PCB:	Max450mm
Transfer Speed:	400 -1800mm/min
Preheater Power:	21.6KW
Tin Furnace Power:	18KW
Transmission Motor:	1ΦPAC220V 90W
Cooling Fan:	1ΦAC220V 370W
Tin Wave Motor:	2-3ΦPAC220V 370W
Cleaning Motor:	1ΦPAC220V 30W
Tin Furnace Capacity:	520kg

Product Description

Features:
* Windows10 operating system,which can realize free switching between English and Chinese in the operation interface.
* Modular design,convenient and fast maintenance,reducing maintenance time and cost
* Four-stage independent drawer type super long ho tair preheating zone can effectively reduce the temperature difference of over-fumace products and improve product quality.
* Tin furnace is equipped with electrlc lifting and running mechanism as standard,and both operation surface and back surface can be operated.
* Tin furnace standard with heating secondary monitoring foolproof system,can effectively prevent abnormal heating of tin furnace
* The equipment is equipped with a pressure tank constant pressure storage system to ensure that the pressure in the flux spraying is relatively stable.
* The equipment is equipped with various sound and light alarm and prompt functions,including temperature devlation,speed devlation,wave and wind fault,wrong operation,eto.
