Dual Platform Selective Wave Soldering Machine 380V for PCB

Name: Dual Platform Selective Wave Soldering Machine 380V for PCB
Brand: Global Soul Limited
SKU: SM-LⅡ
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: GS

Model Number: SM-LⅡ

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Price: USD+negotiable+pcs

Packaging Details: 3100*1800*1800mm

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                Dual Platform Selective Wave Soldering Machine, Selective Wave Soldering Machine 380V


Machine Size(mm):	2950(L)1650(W)1675(H)	Total Machine Power/operating Power:	20KW/6-8KW
Power Supply:	380V/Single-phase 380V	Net Weight:	1500Kg
Air Source Requirements:	Pressure 0.4-0.6MPa, Flow Rate 8-12L	Nitrogen Gas Source Requirements:	Pressure 0.3-0.5MPa, Flow Rate Not Less Than 5 Cubic Meters Per Hour, Purity Not Less Than 99.998%
Air Volume Requirements:	Above The Spray: 800-1000cbm/h; Above The Tin Furnace: 600-800cbm/h	Pallet Passing Size:	L260×W 260-L500×W500 Mm (Pallet Process Edge Thickness: 3- 10mm)
Double Nozzle Spacing:	165~265 Mm	Maximum Welding Area:	L500×W500 Mm

Machine Size(mm):	2950(L)1650(W)1675(H)
Total Machine Power/operating Power:	20KW/6-8KW
Power Supply:	380V/Single-phase 380V
Net Weight:	1500Kg
Air Source Requirements:	Pressure 0.4-0.6MPa, Flow Rate 8-12L
Nitrogen Gas Source Requirements:	Pressure 0.3-0.5MPa, Flow Rate Not Less Than 5 Cubic Meters Per Hour, Purity Not Less Than 99.998%
Air Volume Requirements:	Above The Spray: 800-1000cbm/h; Above The Tin Furnace: 600-800cbm/h
Pallet Passing Size:	L260×W 260-L500×W500 Mm (Pallet Process Edge Thickness: 3- 10mm)
Double Nozzle Spacing:	165~265 Mm
Maximum Welding Area:	L500×W500 Mm

Product Description

Online Dual Platform Selective Wave Soldering Machine Single phase 380V

Product Specifications

Attribute	Value
Machine size(mm)	2950(L)1650(W)1675(H)
Total machine power/operating power	20KW/6-8KW
Power supply	380V/Single-phase 380V
Net weight	1500Kg
Air source requirements	Pressure 0.4-0.6MPa, flow rate 8-12L
Nitrogen gas source requirements	Pressure 0.3-0.5MPa, flow rate ≥5 m³/h, purity ≥99.998%
Air volume requirements	Above spray: 800-1000cbm/h; Above tin furnace: 600-800cbm/h
Pallet passing size	L260W260-L500W500 mm (Pallet edge thickness: 3-10mm)
Double nozzle spacing	165~265 mm
Maximum welding area	L500*W500 mm

Key Features

Industrial computer with multi-axis motion control card for high-precision motion control
Custom control software supports PCB images/GERBER files for path editing with adjustable parameters
Automatic monitoring and recording of critical process parameters with fault alarm system
Preset formula function for saving and recalling process parameter configurations
Precision aluminum construction with ball screw and servo motor drive for accurate, low-noise operation
Dual-stage product delivery system with aluminum guide rail/roller chain and stainless steel roller structures
Real-time welding process monitoring with camera feed, photo capture, and video recording capabilities
Sturdy steel welded frame construction for long-term stability and durability

Online Dual Platform Selective Wave Soldering | GSSMT, Dual platform selective wave soldering, Online selective wave soldering machine, Selective wave soldering dual platform, Online wave soldering for SMT, Dual platform wave soldering system, Selective wave soldering equipment, Online dual platform soldering, Dual platform selective soldering machine, Selective soldering wave machine, Dual platform online soldering system, Online selective soldering for PCB, Selective wave soldering for electronics, High-precision selective wave soldering, Automated dual platform wave soldering, SMT selective wave soldering online, Online wave soldering equipment, Dual platform selective soldering technology, Online selective wave soldering system, High-speed dual platform wave soldering, SMT dual platform selective wave soldering
