GSCJ-8301B1-5 PCB Magazine Loader 355x500x563mm 5-Sheet Side Board

Name: GSCJ-8301B1-5 PCB Magazine Loader 355x500x563mm 5-Sheet Side Board
Brand: Global Soul Limited
SKU: GSCJ-8301B1-5
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: GS

Model Number: GSCJ-8301B1-5

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Price: USD+negotiable+pcs

Packaging Details: 380*520*580mm

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                Automatic PCB Magazine Loader, Automatic PCB Magazine Unloader, GSCJ-8301B1-5 Automatic PCB Loader


Size:	355 X 500 X 563 Mm	Adjustment Method:	Handle
Base Material:	Plate Metal	Reference Position:	A34 Mm, B34 Mm
Side Board Structure:	5 Sheets	Lead Time:	1-7 Days

Size:	355 X 500 X 563 Mm
Adjustment Method:	Handle
Base Material:	Plate Metal
Reference Position:	A34 Mm, B34 Mm
Side Board Structure:	5 Sheets
Lead Time:	1-7 Days

Product Description

GSCJ-8301B1-5 PCB Magazine Loader And Unloader Rack

Automatic PCB Loader with Storage and Transfer Frame

The GSCJ-8301B1-5 is an automatic loading and unloading rack system designed for efficient handling of PCBs and substrate boxes. This robust magazine loader provides secure storage and smooth transfer capabilities for circuit board manufacturing processes.

Key Features

Automatic PCB loading and unloading system
Secure storage frame for circuit boards
Efficient transfer mechanism
Compatible with various PCB magazine types
Sturdy construction for industrial environments

Installation Guide

Install the Rack: Ensure the rack is aligned and flush with the base plate.
Secure the Columns: Use screws to fix the four columns firmly.
Attach the Side Panel: Align the holes and tighten the screws.
Position the Movable Side Panel: Ensure the bottom edge is close to the rack.
Install the Base Plate: Push the circular pin of the latch upward and move the side panel.
Install the Stopper: Attach it at the spring position, facing downward.

Special Note: Pay particular attention to steps 4 and 5. The circular pin of the latch must align precisely with the circular hole on the base plate. Accurate positioning is crucial to avoid misalignment; ensure synchronization in all directions.
