RX-7R Compact SMT Pick And Place Machine 56 Feeder Capacity

Name: RX-7R Compact SMT Pick And Place Machine 56 Feeder Capacity
Brand: Global Soul Limited
SKU: RX-7R
Price: 3,000.00 USD
Availability: InStock

Product Details

Place of Origin: Japan

Brand Name: JUKI

Model Number: RX-7R

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Price: USD+negotiable+pcs

Packaging Details: 1100*2000*1600mm

Delivery Time: 1-7 days

Payment Terms: T/T

Supply Ability: 1+pcs+per days

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                Fast Assembly Pick And Place Machine, Speed SMT Pick And Place Machine, Compact SMT Pick And Place Machine


Model Number:	RX-7R	Feeder Capacity:	Up To 56
Power Supply:	3 Phase AC200V,220V-430V	Apparent Power:	2.3kVA
Operating Air Pressure:	0.5±0.05MPa	Air Consumption (standard):	20L/ANR(during Normal Operation)
Machine Dimensions (W X D X H):	998×1,895×1,530mm	Mass (approximately):	About 1,820kg

Model Number:	RX-7R
Feeder Capacity:	Up To 56
Power Supply:	3 Phase AC200V,220V-430V
Apparent Power:	2.3kVA
Operating Air Pressure:	0.5±0.05MPa
Air Consumption (standard):	20L/ANR(during Normal Operation)
Machine Dimensions (W X D X H):	998×1,895×1,530mm
Mass (approximately):	About 1,820kg

Product Description

RX-7R Compact Speed SMT Pick And Place Machine

Key Specifications

Attribute	Value
Model number	RX-7R
Feeder capacity	Up to 56
Power supply	3 phase AC200V,220V-430V
Apparent power	2.3kVA
Operating air pressure	0.5±0.05MPa
Air consumption (standard)	20L/ANR(during normal operation)
Machine dimensions (W × D × H)	998 × 1,895 × 1,530mm
Mass (approximately)	about 1,820kg

Product Overview

The RX-7R Compact Speed SMT Pick and Place Machine features significant upgrades in PCB handling flexibility and placement accuracy through its innovative placement head design. This high-speed mounting system is optimized for smaller components while maintaining Juki's renowned reliability.

Key Features

Dual lane conveyor supports two L-size PCBs (420 x 450mm) while maintaining compact machine dimensions
P16S placement head with new axial design for enhanced angular placement accuracy
Ideal for LED board production with growing market demands
Compatible with flexible mounter combinations for complete production lines
Configurable with either fixed feeder banks or feeder trolleys
Conveyor options available for dual or single lane operation

The RX-7R represents the continued evolution of Juki Smart Solutions, delivering improved flexibility and capability while providing Total Line Solutions for modern SMT production environments.
