Highlight:
SMT Pick And Place Machines
, KEYAN-K3 Solder Paste Printer
, Full Automatic Solder Paste Printer
Machine Performance Visual Alignment Accuracy: |
±0.02mm |
Print Accuracy: |
±0.03mm |
Printing Cycle（Printing Time Is Not Included）: |
＜15sec/P |
Printing Parameters Snap-off: |
0~10mm/S |
Printing Mode: |
Single/double Doctorate Printing |
Scraper Pressure: |
0.5~10kg |
Scraper Angle: |
Standrd Type 45°55°60° |
Print Speed: |
10~200mm/sec |
Printing Strokes: |
50mm~520mm |
The Template Frame Size: |
470mm*370mm~800mm*800mm |
Cleaning Method: |
Dry And Wet Methods |
Vision System Camera: |
High Frame Rate CCD Image Processing Camera |
Identify The Cardinal Point: |
Round, Square, Diamond, Text, Pad And Special-shaped |
Image Method: |
Single Photo, Double Photo, Foolproof (camera Can Be Turned Off Completely) |
Detection Function: |
2D Visual Inspection |
PCB Base Board Processing Maximum Board Size: |
600*400mm |
Minimum Board Size: |
50*50mm |
Board Thickness: |
0.4~6mm |
Maximum Board Weight: |
10Kg |
Transmission Height: |
900±40mm |
Transport Speed: |
1200mm/sec（MAX） |
Transport Direction: |
One-piece Transport Rails |
Transport Direction: |
(Left-right, Right-left, Left-left, Right-right) Software Control |
Board Clamp: |
Self-controlled Splints |
SUpport Method: |
Magnetic Ejector Pin, Magnetic Ejector Block(manually Adjusted Jacking Platform) |
Device Details Platform Correction Range: |
X:±3mm；Y:±7.5mm；θ:±2° |
Power Supply: |
AC 220V 50/60Hz Single Phase 2KW |
Ambient Humidity: |
25%~65% |
Ambient Temperature: |
-18 ℃ ~50℃ |
Device Dimensions: |
L=1200*W=1300*H=1410mm |
Inlet Pressure: |
4~6kgf/c㎡ |
Changeover Time: |
＜5min |
Device Weight: |
500kg |
Condition: |
Original New |
SMT Pick And Place Machines Full Automatic Solder Paste Printer KEYAN-K3
Key Features
- ±0.02mm precision for regular PCB printing needs
- Pneumatic control of double scraper (0.5~10kg adjustment)
- Lightweight 500kg design with small footprint
- Energy efficient 1.5KW low power consumption
- Ideal for smart homes and small industrial equipment production
Technical Specifications
| Attribute |
Value |
| Visual alignment accuracy |
±0.02mm |
| Print accuracy |
±0.03mm |
| Printing cycle |
<15sec/P |
| Printing Mode |
Single/double doctorate printing |
| Scraper pressure |
0.5~10kg |
| Scraper angle |
Standard type 45°55°60° |
| Print Speed |
10~200mm/sec |
| Maximum board size |
600*400mm |
| Board thickness |
0.4~6mm |
| Device dimensions |
L=1200*W=1300*H=1410mm |
| Device weight |
500kg |
| Power supply |
AC 220V 50/60Hz single phase 2KW |
Product Description
The KEYAN-K3 provides economical and practical printing solutions for small and medium-sized mass production, featuring a lightweight design and low energy consumption. Its precision engineering meets regular PCB printing needs while offering cost-effective operation and fast return on investment.
