Highlight:
950KG 3D AOI MV-6E
, SPC 3D AOI MV-6E
, MIRTEC 3D AOI MV-6E
Model: |
MV-6E (OMNI) |
PCB Size: |
50mm×50mm~480mm×460mm |
Height Accuracy: |
±3um |
Maximum Component Height: |
5mm |
2D Detection Items: |
Missing Piece, Offset, Skew, Stellation, Side Stand, Turn Over Piece, Polar Reverse, Wrong Piece, Damage, Tin, Virtual Welding, Cavity, OCR |
3D Detection Items: |
Missing Parts, Height, Position, More Tin, Less Tin, Missing Welding, Double Chip, Size, IC Foot Virtual Welding, Foreign Matter, Parts Cocking, BGA Cocking, Climbing Tin Detection, Etc |
FOV Field Of View: |
58.56mm×58.56mm |
3D Detection Speed: |
0.80 Seconds /FOV/4.260mm²/ Second |
2D Detection Speed: |
0.30 Seconds /FOV/ 10,716 Mm²/ Second |
Lens: |
Accurate Telecentric Composite Lens |
Lighting System: |
8-segment Color Lighting System |
SPC: |
Complete Statistical Software |
PCB Clearance: |
45mm |
PCB Thickness: |
0.5~5mm |
Minimum Measurement Size: |
03015 |
Positioning System: |
Servo Motor |
Repeatability: |
±10um |
3D Detection Technology: |
DVLP 8-group Moorfringe Technology |
Appearance Size: |
1080 (W) ×1470 (D) 1560 (H) |
Weight: |
950KG |
Air Source: |
5KGf/cm² (0.5Mpa) |
Power Supply: |
200-240VAC 50Hz/60Hz |
